943 851 858
ERLO Units
Roller units
Roller units CA-30
- For modular assembly
- Stroke: 250 mm
- Spindle: 8000 N
- Push force: 30 m/min
More product information:
| Features | CA 30 |
|---|---|
| Stroke | 250 mm |
| Push force | 8000 N |
| Feed speed | 30 m/min |
| Maximum moment (Mx) | 840 Nm |
| Maximum moment (My) | 660 Nm |
| Spindle | Ø 25 x 5 |
| Weight (without motor) | 75 kg |
Settings system
| CA.30 | PR | 801 | 0 |
|---|---|---|---|
| 1 | 2 | 3 |
1 - Guide protection
- PR: Guideway protection with wiper (standard)
- PF: Guideway protection with bellows
- PT: Guideway protection with telescopic guard
2 - Transmission
| Ø Flange | Ø Shaft | |
|---|---|---|
| 801 | Ø 80 | Ø 14 |
| 802 | Ø 80 | Ø 16 |
| 803 | Ø 80 | Ø 19 |
| 811 | Ø 90 | Ø 19 |
3 - Micrometric scale
- 0: Roller unit without micrometric scale
- R: Roller unit with micrometric scale to the right
- L: Roller unit with micrometric scale to the left
